UL21394 COILED CABLE 卷线

UL21394 COILED CABLE 卷线

  • 所属分类:UL低烟无卤
  • 浏览次数:0
  • 发布时间:2022-08-05 16:57:03
  • 产品概述

UL21394 COILED CABLE 卷线

■说明
●导体绞线,镀锡或裸软铜线
●PVC/SR-PVC/PP/TPU/XL-PE 绝缘
●TPE 被覆
●额定温度:80°C;额定电压:30volts
●使用标准厚度,易剥,截断容易
●可通过UL VW-1&CUL FT1/FT2 垂直耐燃测试
●镀锡或裸软铜缠绕或编织隔离
●多芯可使用纸巾、铝箔或麦拉隔离
●参考标准:UL758 UL1581 CSA22.2

■应用
●用于电子以及电器设备内部连线


■PRODUCT DESCRIPTION
●Tinned,annealed,stranded or solid copper conductor.
●PVC/SR-PVC/PP/TPU/XL-PE insulation.
●TPE jacketed.
●Rated temperature:80°C.Rated voltage:30volts
●Uniform thickness of wire to ensure easy stripping and cutting.
●Passes UL VW-1&CUL FT1/FT2 vertical flamt test.
●Tinned or bare copper winding or woven isolation.
●A collection of cores can be isolated tissue paper package,aluminum foil or mylar.
●Executive Standard:UL758 UL1581 CSA22.2.

■APPLICATION
●For general purpose internal wiring of electronic and electrical equipment


■产品结构CABLE CONSTRUCTION
UL Style
& CSA Type
 Conductor
Cores
Conductor Insulation
 Thickness
 Nom.Dia   Jacket ThicknessOverall
 Diameter
Conductor
Resistance(20°C)
 AWGNo/mmmmmmmmmmΩ/KM
UL21394(Stranded)2C307/0.100.250.800.83.40354
287/0.1270.903.60223
267/0.161.003.90139
2411/0.161.104.1088.9
2217/0.161.304.657.5
2021/0.1781.505.0034.6
1834/0.1781.805.6023.3
3C307/0.100.250.800.83.70354
287/0.1270.904.00223
267/0.161.004.20139
2411/0.161.104.5088.9
2217/0.161.304.8057.5
2021/0.1781.505.3034.6
1834/0.1781.806.0023.3
4C307/0.100.250.8014.30354
287/0.1270.904.60223
267/0.161.004.80139
2411/0.161.105.1088.9
2217/0.161.305.5057.5
2021/0.1781.506.1034.6
1834/0.1781.806.8023.3
5C307/0.100.250.8014.50354
287/0.1270.904.90223
267/0.161.005.20139
2411/0.161.105.4088.9
2217/0.161.306.0057.5
2021/0.1781.506.7034.6
1834/0.1781.807.4023.3
6C307/0.100.250.8014.90354
287/0.1270.905.30223
267/0.161.005.60139
2411/0.161.106.0088.9
2217/0.161.306.4057.5
2021/0.1781.507.0034.6
1834/0.1781.807.9023.3
